Laser & Process Water Chiller

  • TEYU CHE-20T

    Model CHE-20T-03RTY
    Max. Heat Exchange Capacity 200W
    Dimension 25 × 8 × 60 cm
    Net Weight 4kg

상세정보

Dual Protection

Dual Protection

稳固耐用

Flexible Compatibility

只能保护

Anti-Condensation

体积小巧

Simple Structure

Product Parameters

Model

CHE-20T-03RTY

Voltage

1/PE AC 220V

Frequency

50/60Hz

Current

0.2A

Max. power consumption

28/22W

Radiating capacity

10W/℃

N.W.

4kg

Max. Heat Exchange Capacity

200W

G.W.

5kg

Dimension

25 × 8 × 60 cm (L × W × H)

Package dimension

32 × 14 × 65 cm (L × W × H)



Note: The heat exchanger is designed for a maximum temperature difference of 20°C.

More details

External Air Inlet


Draws in ambient air through the external circulation channel, equipped with protective design to block dust, oil mist, and moisture from entering the cabinet.

TEYU CHE-20T Cabinet Heat Exchanger for CNC and Industrial Control Cabinets

External Air Outlet


Expels processed air smoothly to maintain efficient heat exchange, ensuring stable cooling performance and reliable protection in harsh industrial environments.

TEYU CHE-20T Cabinet Heat Exchanger for CNC and Industrial Control Cabinets

Internal Air Outlet


Distributes cooled internal air evenly inside the cabinet, keeping temperature stable and preventing hotspots for sensitive electrical components.

TEYU CHE-20T Cabinet Heat Exchanger for CNC and Industrial Control Cabinets

Installation methods

TEYU CHE-20T Cabinet Heat Exchanger for CNC and Industrial Control Cabinets
