Laser & Process Water Chiller
Laser & Process Water Chiller
-
TEYU ECU-1200
Model ECU-1200T-03RTY Rated cooling capacity 1440W Dimension 36 × 19 × 75 cm Net Weight 28kg
상세정보
TEYU ECU-1200
TEYU ECU-1200 delivers 1200/1440W of efficient cooling with precise digital temperature control. Ideal for CNC systems, electrical cabinets, laser equipment, and industrial enclosures, it ensures stable performance, protects equipment, and boosts productivity.
Eco-Friendly Refrigerant
Stable and durable
Intelligent protection
Compact & Light
Product Parameters
|
Model |
ECU-1200T-03RTY |
Voltage |
AC 1P 220V |
|
Frequency |
50/60Hz |
Ambient temperature range |
﹣5~50℃ |
|
Rated cooling capacity |
1200/1440W |
Set temperature range |
25~38℃ |
|
Max. power consumption |
638/735W |
Rated current |
4.4/5.8A |
|
Refrigerant |
R-134a |
Refrigerant charge |
300g |
|
Noise level |
≤63dB |
Internal circulation airflow |
300m³/h |
|
Power connection |
Reserved wiring terminal |
External circulation airflow |
500m³/h |
|
N.W. |
28kg |
Power cord length |
2m |
|
G.W. |
29kg |
Dimension | 36 × 19 × 75 cm (L × W × H) |
|
Package dimension |
43 × 26 × 82 cm (L × W × H) |
The working current can be different under different working conditions. The above information is for reference only. Please subject to the actual delivered product.
More details
Accurately manages cabinet temperature to ensure reliable, long-lasting performance.
Condenser Air Inlet
Provides smooth, efficient airflow intake for optimal heat dissipation and stability.
Air Outlet (Cool Air)
Delivers steady, targeted cooling airflow to safeguard sensitive components.
Panel Opening Dimensions & Component Description
Installation methods
Note: Users are advised to make selections based on their specific usage requirements.
