TEYU ECU-800
Model ECU-800T-03RTY Rated cooling capacity 960W Dimension 35 × 19 × 63 cm Net Weight 21kg
상세정보
TEYU ECU-800
TEYU ECU-800enclosure cooling unit delivers precise digital temperature control and energy-efficient cooling for CNC systems, electrical cabinets, and industrial equipment. With 800/960W capacity, quiet operation, and reliable condensate solutions, it ensures stable performance and long-term protection.
Eco-Friendly Refrigerant
Stable and durable
Intelligent protection
Compact & Light
Product Parameters
|
Model |
ECU-800T-03RTY |
Voltage |
AC 1P 220V |
|
Frequency |
50/60Hz |
Ambient temperature range |
﹣5~50℃ |
|
Rated cooling capacity |
800/960W |
Set temperature range |
25~38℃ |
|
Max. power consumption |
485/501W |
Rated current |
3.4/4.2A |
|
Refrigerant |
R-134a |
Refrigerant charge |
230g |
|
Noise level |
≤60dB |
Internal circulation airflow |
230m³/h |
|
Power connection |
Reserved wiring terminal |
External circulation airflow |
320m³/h |
|
N.W. |
21kg |
Power cord length |
2m |
|
G.W. |
23kg |
Dimension | 35 × 19 × 63 cm (L × W × H) |
|
Package dimension |
43 × 26 × 70 cm (L × W × H) |
The working current can be different under different working conditions. The above information is for reference only. Please subject to the actual delivered product.
More details
Accurately manages cabinet temperature to ensure reliable, long-lasting performance.
Condenser Air Inlet
Provides smooth, efficient airflow intake for optimal heat dissipation and stability.
Air Outlet (Cool Air)
Delivers steady, targeted cooling airflow to safeguard sensitive components.
Panel Opening Dimensions & Component Description
Installation methods
Note: Users are advised to make selections based on their specific usage requirements.
