TEYU ECU-300
Model ECU-300T-03RTY Rated cooling capacity 360W Dimension 29 × 16 × 46 cm Net Weight 13kg
상세정보
TEYU ECU-300
TEYU ECU-300 enclosure cooling unit delivers efficient, reliable cooling for CNC cabinets, machine tools, and electrical enclosures. Featuring a compact design, low-noise performance, and flexible condensation options, it ensures stable operation across diverse industrial environments.
Eco-Friendly Refrigerant
Stable and durable
Intelligent protection
Compact & Light
ProductParameters
|
Model |
ECU-300T-03RTY |
Voltage |
AC 1P 220V |
|
Frequency |
50/60Hz |
Ambient temperature range |
﹣5~50℃ |
|
Rated cooling capacity |
300/360W |
Set temperature range |
25~38℃ |
|
Max. power consumption |
220/244W |
Rated current |
1.3A |
|
Refrigerant |
R-513A |
Refrigerant charge |
150g |
|
Noise level |
≤58dB |
Internal circulation airflow |
120m³/h |
|
Power connection |
Three-pin plug |
External circulation airflow |
160m³/h |
|
N.W. |
13kg |
Power cord length |
2m |
|
G.W. |
14kg |
Dimension | 29 × 16 × 46 cm (L × W × H) |
|
Package dimension |
35 × 21 × 52 cm (L × W × H) |
The working current can be different under different working conditions. The above information is for reference only. Please subject to the actual delivered product.
More details
Accurately manages cabinet temperature to ensure reliable, long-lasting performance.
Condenser Air Inlet
Provides smooth, efficient airflow intake for optimal heat dissipation and stability.
Air Outlet (Cool Air)
Delivers steady, targeted cooling airflow to safeguard sensitive components.
Panel Opening Dimensions & Component Description
Installation methods
Note: Users are advised to make selections based on their specific usage requirements.
